ASROCK H110M-DVS R2.0

2.390.000 ₫

Mô tả
Đánh giá (0)

Thông số kỹ thuật

ASROCK H110M-DVS R2.0 là một trong những bo mạch chủ giá rẻ dành cho những ai đang có ý định xây dựng một hệ thống máy tính phổ thông nhưng lại được tích hợp những công nghệ mới nhất hiện nay như hỗ trợ cho các dòng chip Skylake socket 1151 và bộ nhớ Ram DDR4

Mục Lục

Hình ảnh sản phẩm

asrock-h110m-dvs-r2-0-skytech.company-2

Thông số kỹ thuật

Mainboard-Bo mạch chủ của hệ thống máy tính.

Unique Feature	ASRock Super Alloy – Matte Black PCB – High Density Glass Fabric PCB ASRock Full Spike Protection ASRock Live Update & APP Shop
CPU	Supports 7^th and 6^th Generation Intel^® Core™ i7 / i5 / i3 / Pentium^® / Celeron^® Processors (Socket 1151) – Supports CPU up to 91W – Digi Power design – 5 Power Phase design – Supports Intel^® Turbo Boost 2.0 Technology
Chipset	– Intel^® H110
Bộ nhớ RAM	– Dual Channel DDR4 Memory Technology – 2 x DDR4 DIMM Slots – Supports DDR4 2400/2133 non-ECC, un-buffered memory* – Supports ECC UDIMM memory modules (operate in non-ECC mode) – Max. capacity of system memory: 32GB** – Supports Intel^® Extreme Memory Profile (XMP) 2.0 7th Gen Intel^® CPU supports DDR4 up to 2400; 6^th Gen Intel^® CPU supports DDR4 up to 2133. *Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows^® 32-bit OS. For Windows^® 64-bit OS with 64-bit CPU, there is no such limitation.
BIOS	– 64Mb AMI UEFI Legal BIOS with multilingual GUI support – ACPI 5.0 Compliant wake up events – SMBIOS 2.7 Support – CPU, DRAM, PCH 1.0V, VCCIO Voltage Multi-adjustment
Card đồ họa	– Supports Intel^® HD Graphics Built-in Visuals : Intel^® Quick Sync Video with AVC, MVC (S3D) and MPEG-2 Full HW Encode1, Intel^® InTru™ 3D, Intel^® Clear Video HD Technology, Intel^® Insider™, Intel^® HD Graphics 510/530/630 – Pixel Shader 5.0, DirectX 12 – Max. shared memory 1024MB* – Dual graphics output: Support DVI-D and D-Sub ports by independent display controllers – Supports DVI-D with max. resolution up to 1920×1200 @ 60Hz – Supports D-Sub with max. resolution up to 1920×1200 @ 60Hz – Supports Accelerated Media Codecs: HEVC, VP8, VP9 – Supports HDCP with DVI-D Port – Supports Full HD 1080p Blu-ray (BD) playback with DVI-D Port The size of maximum shared memory may vary from different operating systems. Intel^® HD Graphics Built-in Visuals and the VGA outputs can be supported only with processors which are GPU integrated. Due to chipset limitation, the Blu-ray playback of Intel^® HD Graphics is only supported under Windows^® 8 / 8 64-bit / 7 / 7 64-bit. **Intel^® InTru™ 3D is only supported under Windows^® 8 / 8 64-bit / 7 / 7 64-bit.
Card âm thanh	– 7.1 CH HD Audio (Realtek ALC887 Audio Codec)* – Supports Surge Protection (ASRock Full Spike Protection) – ELNA Audio Caps *To configure 7.1 CH HD Audio, it is required to use an HD front panel audio module and enable the multi-channel audio feature through the audio driver.
LAN	– PCIE x1 Gigabit LAN 10/100/1000 Mb/s – Realtek RTL8111GR/RTL8111C – Supports Wake-On-LAN – Supports Lightning/ESD Protection (ASRock Full Spike Protection) – Supports LAN Cable Detection – Supports PXE
Khe cắm	– 1 x PCI Express 3.0 x16 Slot (PCIE1: x16 mode)* – 2 x PCI Express 2.0 x1 Slots *Supports NVMe SSD as boot disks
Kho tiền	– 4 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI and Hot Plug
Cổng kết nối	– 1 x Print Port Header – 1 x COM Port Header – 1 x TPM Header – 1 x Chassis Intrusion and Speaker Header – 1 x CPU Fan Connector (4-pin) – 2 x Chassis Fan Connectors (4-pin)* – 1 x 24 pin ATX Power Connector – 1 x 8 pin 12V Power Connector – 1 x Front Panel Audio Connector – 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)) – 1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports) (Supports ESD Protection (ASRock Full Spike Protection))** The CPU Fan Connector supports the CPU fan of maximum 1A (12W) fan power. *USB_11_12 is shared with USB_9_10.
Bảng điều khiển Input/Output phía sau	– 1 x PS/2 Mouse/Keyboard Port – 1 x D-Sub Port – 1 x DVI-D Port – 4 x USB 2.0 Ports (Supports ESD Protection (ASRock Full Spike Protection))* – 2 x USB 3.1 Gen1 Ports (Supports ESD Protection (ASRock Full Spike Protection))* – 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) – HD Audio Jacks: Line in / Front Speaker / Microphone *ACPI wake-up function is supported on the rear USB ports only.
Phần mềm và UEFI	Software – ASRock Disk Health Report – ASRock USB Key – ASRock APP Charger – ASRock XFast LAN – ASRock XFast RAM – ASRock Fast Boot (Fast Boot, Restart to UEFI) UEFI – ASRock EZ Mode – ASRock My Favorites in UEFI – ASRock Instant Flash – ASRock Internet Flash – ASRock Crashless BIOS – ASRock OMG (Online Management Guard) – ASRock UEFI Tech Service – ASRock Easy Driver Installer *These utilities can be downloaded from ASRock Live Update & APP Shop.

Công ty SkyTech chuyên phân phối mainboard-Bo mạch chủ và đảm bảo về chất lượng uy tín lên hàng đầu, giá cả rất tốt trên thị trường và luông mang đến cho khách hàng chính sách bảo hành, chất lượng dịch vụ, tư vấn tận tâm nhất.

Nếu các bạn đang có ý định lắp đặt một hệ thống máy tính thì hãy liên hệ ngay với hotline sửa laptop giá rẻ tại đà nẵng 0708.08.4444 để được tư vấn và giải đáp thắc mắc hoặc đến trực tiếp công ty Công Ty Tnhh Công Nghệ Và Giải Pháp Sky của chúng tôi.
